Fusion PF-CM650 6.5″ Component Speakers
Specifications
Crossover Specifications
Crossover Type 2nd Order Mounting Dimensions
Mounting Depth 60mm (2-3/8?) Mounting Diameter 132mm (5-1/4?) Product Specifications
Basket Steel Frame Cone Material IMPP Frequency Response 29Hz ? 30kHz Peak Power (Watts) 280 Rated Power (Watts) 50 Sensitivity (dB) 89 Surround Material PU Thiele Small Parameters
Compliance (Cms) (mm/N) 0.628 Cone Area (Sd) (cm?) 118.82 D.C. Coil Resistance (Re) (Ohm) 3.10 Diaphragm Mass (Mmd) (g) 12.965 Electrical Q (Qes) 0.623 Force Factor (Bl) (TM) 4.823 Free Air Resonance (Fs) (Hz) 54.3 Mechanical Q (Qms) 4.570 Total Loudspeaker Q (Qts) 0.548 VAS (CuFt) 0.4432 VAS (L) 12.5501 Voice Coil Impedance 4 Ohm Tweeter Specifications
Tweeter Type Silk Dome SKU: n/a
