We appreciate the investment you go through to enhance the sound reproduction in your vehicle and we take that very seriously. We utilize the latest Distortion meters imported from Steve Meads Design USA to ensure that once your amplifier is tuned correctly and there is no distortion present that can deteriorate and destroy your loudspeakers prematurely.
Amps Categories
Amps
Showing all 20 results
-
2 Channel, DB Drive
DB Drive A380.2 2 Ch Amp 280 Watt
Features:
Class AB Amplifier
Rated at 14.4 volts
RMS Wattage: 2 x 75
Capability: 2 ohm stereo
2 x 80 Watts @ 4 ohms
1 x 200 Watts @ 4 ohms (Bridged)
2 x 140 Watts @ 2 ohms
Continuously variable 12dB boost on bass EQ
Buffered pre-amp input circuitry
DriveSink heat management
Fuse rating: 20A x 1
Continuously variable 12dB per octave low pass X-overSKU: n/a -
-
Monoblock, Pioneer
Pioneer GM-D8601Mono 1600W Class-D Car Amp, with Bass Boost Remote
Features
-
Maximum Output Power1 x 600 W (4 ohm)
1 x 1000 W (2 ohm)
1 x 1600 W (1 ohm) -
CEA 2006 Power (THD N = 1%)1 x 300 W (20 Hz ? 240 Hz / 4?)
1 x 500 W (100 Hz / 2?)
1 x 800 W (100 Hz / 2?)
75 dBA (ref: 1 W into 4?) -
Continuous power output (RMS)1 x 300 W RMS (4?)
1 x 500 W RMS (2?)
1 x 800 W RMS (1?) -
Frequency response10 ? 240?Hz
-
Distortion10 W, 100 Hz ref. < 0.5?%
-
S/N ratio> 100?dB
-
Bass BoostRemote Control
Frequency 50Hz, Level 0-18dB -
LPF40 ? 240 Hz (-12 dB/oct)
-
RCA terminals
-
Speaker TerminalsBlock-type
-
Speaker line input sensorTurn-on sensor
-
Input level controlRCA (0.2V ? 6.5V)
SP (0.8V ? 16V) -
Max. current consumption (A/4?)24 A
-
Chassis size (W x H x D)265 x 60 x 200 ?mm
-
Unit weight2.7 ?kg
SKU: n/a -
-
Monoblock, Pioneer
Pioneer GM-D9601 Mono 2400W Class-D Car Amp, with Bass Boost Remote
-
Maximum Output Power?1 x 1000 W (4?)
1 x 1600 W (2?)
1 x 2400 W (1?) -
CEA 2006 Power (THD N = 1%)1 x 500 W (100 Hz / 2?)
1 x 800 W (100 Hz / 2?)
1 x 1200 W (50 Hz / 2?)
75 dBA (ref: 1 W into 4?) -
Continuous power output (RMS)1 x 500 W RMS (4?)
1 x 800 W RMS (2?)
1 x 1200 W RMS (1?) -
Frequency response10 ? 240?Hz
-
Distortion10W, 100 Hz ref. < 0.5?%
-
S/N ratio> 100?dB
-
Bass BoostRemote Control
Frequency 50 Hz, Level 0-18 dB -
LPF40 ? 240 Hz (-12 dB/oct)
-
RCA terminals
-
Speaker TerminalsBlock-type
-
Speaker line input sensorturn-on sensor
-
Input level controlRCA (0.2V ? 6.5V)
SP (0.8V ? 16V) -
Max. current consumption (A/4?)39 A
-
Chassis size (W x H x D)315 x 60 x 200 ?mm
-
Unit weight3.3 ?kg
SKU: n/a -
-
Monoblock, Rockford Fosgate
Rockford Fosgate R1200-1D 1,200 Watt Class-D Mono Amplifier
The PRIME R1200-1D is an ultra-efficient mono amplifier that can produce 1,200 Watts into a 1-Ohm load without taxing the electrical system. The frequency response of the R1200-1D is optimized exclusively for use with subwoofers.
- 12dB/octave Butterworth crossover
- Infrasonic filter
- Remote PLC (Punch Level Control)
- RCA pass-thru outputs
- Real time output and power supply thermal sensing
- Cast aluminum heatsink
- Top mounted controls
- 4 Gauge power/ground connectors
- MOSFET power supply
- Short circuit protection
Number of Channels: 4 Rated Power
(RMS Continuous Power):400 Watts x 1 @ 4-Ohm
800 Watts x 1 @ 2-Ohm
1200 Watts x 1 @ 1-OhmTotal Power
(Sum of Rated Power):1200 Watts RMS Dynamic Power
(PVC/PowerCube?):499 Watts x 1 @ 4-Ohms 0? Res
898 Watts x 1 @ 2-Ohms 0? Res
1,400 Watts x 1 @ 1-Ohm 0? ResBridgeable: No Frequency Response: 20Hz to 250Hz /-1dB Efficiency (average): 85% @ 4-Ohm
85% @ 2-Ohm
80% @ 1-OhmTotal Harmonic Distortion(THD Noise): 4-Ohm: <1.0%
2-Ohm: <1.0%
1-Ohm: <1.0%Crossover Controls: Low-Pass: Variable 50Hz – 500Hz @ 12dB/Octave
Infrasonic:Tone Controls: 0dB to 18dB @ 45Hz Input Sensitivity: 150 mV to 4 V Signal Input: Low Level: 1 RCA Pair Signal Output: Low Level: 1 RCA Pair Power Input Connector: Block Power Wire Gauge: 4 AWG Speaker Output Connector: Block Speaker Wire Gauge: 12 AWG Heat Sink Type: Cast aluminum Cooling: Convection Remote Controls: Variable 0dB to 12dB @ 45Hz Visual Indicators: Power
ProtectCircuit Topology Class: Class-D Operating Voltage: 9 – 16 VDC Recommended Fuse
(not included):150 A Max. Current Draw (13.8V Sinewave): 110 A Average Current Draw (13.8V Music): 55 A Suggested Alternator: 100 A Shipping Weight: 7.825 Lbs. (7.82 Kg.) Dimensions (H x W x D): 1.97″ x 6.77″ x 11.06″
(5cm x 17.20cm x 28.10cm)SKU: n/a
