Fusion Performance PF-SW120D2 12″ Subwoofer
Out of stock
Specifications
Mounting Dimensions
| Mounting Depth | 158mm (6-1/4″) |
| Mounting Diameter | 279mm (11″) |
Product Specifications
| Basket | Pressed Steel |
| Cone Material | Pressed Paper |
| Frequency Response | 30Hz – 1.2kHz |
| Peak Power (Watts) | 1600 |
| Rated Power (Watts) | 400 |
| Sensitivity (dB) | 89 |
| Surround Material | Butyl Rubber |
Thiele Small Parameters
| Compliance (Cms) (?M/N) | 112.00u M/N |
| Cone Area (Sd) (cm?) | 530.93 |
| Cone Area (Sd) (In?) | 82.29 |
| D.C. Coil Resistance (Re) (?) | 4.47 Ohm |
| Electrical Q (Qes) | 0.84 |
| Force Factor (Bl) (TM) | 14.04 |
| Free Air Resonance (Fs) | 38.30 |
| Linear Excurson (Xmax) (In) | 0.24 |
| Linear Excurson (Xmax) (mm) | 6.00 |
| Mechanical Excursion (In) | 0.35 |
| Mechanical Excursion (mm) | 9.00 |
| Mechanical Q (Qms) | 2.93 |
| Total Loudspeaker Q (Qts) | 0.65 |
| VAS (CuFt) | 1.58 |
| VAS (L) | 44.69 |
| Voice Coil Impedance | 2 x 2 Ohm |
$90
Out of stock
