Component, Focal
Focal Auditor R-165 S2 2-Way Component Speakers
0 out of 5(0)Specifications:
Diameter 6.5? (165mm)
Mounting depth 2-5/8? (66.5mm)
Voice-coil diameter 1? (25mm)
Voice-coil height 0-7/16? (11mm)
Magnet 3-1/3? (85mm)
Tweeter Silk/Aluminum
Cone Polypropylene
Separated pre wired crossover (12db/oct)
Max power 120W
Nom power 60W RMS
Sensitivity (2.83V/1m) 91.5dB
Frequency response 60Hz-20kHz
Accessories Supplied grillesSKU: n/a -
Component, Fusion
Fusion PF-CM650 6.5″ Component Speakers
0 out of 5(0)Specifications
Crossover Specifications
Crossover Type 2nd Order Mounting Dimensions
Mounting Depth 60mm (2-3/8?) Mounting Diameter 132mm (5-1/4?) Product Specifications
Basket Steel Frame Cone Material IMPP Frequency Response 29Hz ? 30kHz Peak Power (Watts) 280 Rated Power (Watts) 50 Sensitivity (dB) 89 Surround Material PU Thiele Small Parameters
Compliance (Cms) (mm/N) 0.628 Cone Area (Sd) (cm?) 118.82 D.C. Coil Resistance (Re) (Ohm) 3.10 Diaphragm Mass (Mmd) (g) 12.965 Electrical Q (Qes) 0.623 Force Factor (Bl) (TM) 4.823 Free Air Resonance (Fs) (Hz) 54.3 Mechanical Q (Qms) 4.570 Total Loudspeaker Q (Qts) 0.548 VAS (CuFt) 0.4432 VAS (L) 12.5501 Voice Coil Impedance 4 Ohm Tweeter Specifications
Tweeter Type Silk Dome SKU: n/a
